Install of 03-08 Tiburon Aluminum Trip-Meter Switch

$
0
0

Okay so you just recieved your Aluminum trip meter switch and you want to install it , heres what you have to do

Tools needed :
1.) 1 short screw driver
2.) 1 long screw driver



Step 1.) unwrap the Aluminum trip meter switch from the package




Step 2.) Look underneath the cluster bezel you will find two screws, unscrew them and pull the bezel out



Step 3.) You will now see a total of 4 screws that are holding the cluster in place, 2 screws on the left and 2 on the right . Unscrew them and pull the cluster out a little bit enough to see the plugs that are conected to the cluster.



Step 4.) Now that you can see the plugs/conectors that are conected to the cluster you can now unconect them by pulling the out(On my tib i had 2 plugs/conectors).Then after disconecting them pull the cluster out



Step 5.) i forgot to take a picture of this so i took it off the web(google images) but once you have the cluster out , turn it around and you will see it has a few clips that you press down and you will separate the plastic(clear piece) from the cluster


Step 6.)Now that you have them separated you can now pull the old black plastic Trip meter switch out, Do not be afraid it will need quite a bit of force, once you get it out do not lose the spring underneath it.



Step 7.) Okay next you will take the new Aluminum Trip-Meter Switch and you will notice that it crews off and divides itself in 2 parts, Unscrew it and Take the lower part and take the spring that was under the old Trip meter and insert it under the new Aluminum Trip-Meter Switch and push it in in the exact same place where the old Trip-Meter Switch was located



Step 8.) Snap on the clear plastic lenses and screw the other half of the Aluminum Trip-Meter Switch and repeat the steps to install everything back together and your finished. ;)




Also anyone wondering where i got theses i got them off shark racing for $8 shipped.One more thing before i forget if your tib has 2 Trip-Meter Switches you must order 2 of them :3_nosthum
